...includes 54 m2 of a well equipped RF lab including a number of high quality instrument and an ALMA compatible cryostat. The machine shop is a 80 m2 facility where we fabricate microwave devices and support the design and implementation of test set-ups. It includes a CNC milling machine of 1 micrometer of accuracy. 27 m2 are used for storage, cryogenic and air compressors.
The profilometer is a tool that allows us to measure with extremely high precision the topography of a surface, detecting even the smallest roughness or marks
- 250-CNC, SHAUBLIN machines S.A , Switzerland
- Turning machine, resolution z-axis, 0.001mm
- Turbomolecular pumps (Pfeiffer turbocube)
- Leak detector (Pfeiffer HLT570)
- Vacuum sensors
- Temperature monitor (Lakeshore 218)
- ALMA test cryostat (NAOJ)
- 3 stage closed cycle helium system (Sumitomo CNA-61D)
- 2 stage closed system helium system (APD cryogenics)
- Network analysis for transmission line, microwave devices and antenna measurements.
- 10 MHz to 50 GHz.
- 104 dB of dynamic range and <0.006 dB trace noise.
- High precision spectrum analyzer.
- 3Hz to 50 GHz.
- Waveguide Harmonic Mixers (50-75 GHz,75-110 GHz y 220 -330 GHz).
- 2 to 20 GHz.
- Agilent mm-wave Source Module 83554A (20- 40GHz).
- OML Frequency Extension (50-75 GHz y 75-110 GHz).
- VDI Frequency Extension (220-330 GHz).
- Erickson Instruments Power Meter PM3 (>75 GHz ).
- Keysight EPM Power Meter (<18 GHz).
- Anritsu Signal Generator MG3694C (2-40 GHz).
- Keysight EXG Signal Generator N5171B (<6GHz).
- R&S Signal Generator SMB110A (<3.2GHz).
- Keysight CXA Signal Analyzer N9000A (<26.5 GHz).
- Instrumentation amplifier 2 - 50 GHz.
- Two aligned, height-adjustable supports for transmitter and receiver positioning.
- Rotary positioning system for 2D radiation pattern measurements.
- Angular resolution: 0.03°.
- Multi-frequency radiation pattern measurement capability.
- Ansys Electronic Desktop with High Frequency Structure Simulator.
- Cadence AWR Microwave Office.
- WASP-NET.
- Topsolid.
- Books covering microwave fundamentals, Antenna theory and design, Microwave design, Quasi-optical propagation.
- CNC High Precision Micro Milling and Drilling Machine KERN MMP 2522.
- CNC precision machine, precision 1um, 5 axis (Kern).
- Working ranges X 250, Y 220, Z 200 mm.
- Resolution: 0,0001 mm.
- Positioning accuracy: ± 0,001.
- Repetition accuracy: ± 0,001.
- Precision on the workpiece: ± 0,0025.
- Max. feed rate 2.400 mm/min.
- Measurement microscope, precision 1 um (Mitutoyo)
- Semi-automatic bonding machine.
- Equipped with microscope.
- 12.7-76um Gold wire diameter.
- Probe Station for high precision DC and RF measurements.
- Measurements up to 50 GHz.
- Motic PSM 1000 20X – 2000X Microscope.v - 50um and 150um spacing coplanar RF probes.
- 1x ROACH-1 (Virtex-5 FPGA).
- 4x ROACH-2 (Virtex-6 FPGA).
- 2x 3GSPS ADCs.
- 8x 5GSPS ADCs.
- 2x 16 Channels ADCs 250MSPS ADCs.
- Xilinx license for FPGA programming.
- Gold plating.
- Nickel plating.
- Several solutions and vessels for these purposes.
- Gas extractor bench.
- Operational telescope for research and education.
- 1.2 m Cassegrain antenna.
- 2SB Subharmonic Receiver (80-116 GHz).
- Digital spectrometer implemented in ROACH with digital sideband separation.
- High speed laser prototyping machine.
- Capable of implementing planar microwave structures.
- 2um precision.
- Minimal Line width of 50um.
- Minimal spacing of 25um.
- To be used in conjunction with Protolaser S.
- Milling/drilling 1- & 2-sided PCBs.
- Contour routing of circuit boards.
- 2 stereoscopic microscopes.
- 2 Elsa soldering station.
- 1 Hot air soldering station.
- Multiples tools for SMD soldering and microwave packaging.
